I was working on a legacy app recently. The legacy app has angular as its frontend and spring boot app as its backend. Originally the frontend build outputs are committed in the app's git repository and packaged by spring boot by copying them to the ${project.basedir}/target/classes/static/ class path(since content under the folder will be served as static resources by spring boot). And we are using Jenkins pipeline to run the build for this app. Hence the pipeline only use a java jenkins slave to compile and package the spring boot app. But that is not the right way, isn't it?

We should run both build the pipeline for frontend angular app and backend sprint boot app. But an angular app required a node slave to build it out. We don't have a Jenkins slave that has both java and node installed. Then issue comes: How to build java and javascript apps in a single Jenkins pipeline?

Then I found Pipeline allows utilizing multiple agents in the Jenkins environment from within the sameJenkinsfile, which can helpful for more advanced use-cases such as executing builds/tests across multiple platforms.

utilizing multiple agents in Pipeline

Good. We could use node agent to build the angular app and use java agent to compile the spring boot app.

    agent {
        label 'maven' # agent can build java app
    }
    stages {
        stage('Build UI') {
            agent {
                label 'node8' # agent can build javascript app
            }
            steps {
                sh 'npm install'
                sh 'run build'
            }
        }
        stage('Compile') {
            // Build the code to generate the spring-boot jar
            steps {
                sh "mvn -B clean install -f ${POM_FILE}"
            }
        }
    }

The above snippet works well, both frontend and backend got built out. I encountered another challenge: Each agent will run the steps in its own container, which means we are not able to access the dist build out from node agent in the maven agent, since they are using different workspaces.

While I was searching a proper way to address the above concern, I found stash and unstash directives:

stash: Stash some files to be used later in the build
unstash: Restore files previously stashed

Jenkinsfile

pipeline {
    agent {
        label 'maven'
    }
    environment {
        POM_FILE 'server/pom.xml'
    }
    stages {
        stage('Build UI') {
            agent {
                label 'node8'
            }
            steps {
                sh 'npm --prefix=ui install'
                sh 'npm --prefix=ui run build'
                stash includes: 'ui/dist/**', name: 'uidist'
            }
        }
        stage('Compile') {
            // Build the code to generate the spring-boot jar
            steps {
                sh "mvn -B clean install -f ${POM_FILE}"
            }
        }
        stage('Package') {
            // Build the code to generate the spring-boot jar
            steps {
                unstash "uidist"
                sh "ls -all ui/dist"
                sh "mvn -DskipTests=true -B package -f ${POM_FILE}"
            }
        }
    }
}

<plugin>
<artifactId>maven-resources-plugin</artifactId>
<executions>
<execution>
<id>copy-resources</id>
<phase>validate</phase>
<goals>
<goal>copy-resources</goal>
</goals>
<configuration>
<outputDirectory>${project.basedir}/target/classes/static/</outputDirectory>
<resources>
<resource>
<directory>../ui/dist</directory>
</resource>
</resources>
</configuration>
</execution>
</executions>
</plugin>
